Product Name: MH Gantry Crane with Electric Hoist
Lifting capacity: 5～50t
Span: 18～35m
Lifting height: 10～12m
MH model gantry crane is used together with CD1, MD1 model electric hoists, which is a small and medium-sized gantry crane travelling on tracks.
MH model gantry crane with electric hoist is used together with CD1, MD1 model electric hoists, which is a small and medium-sized gantry crane travelling on tracks. The general lifting weight is 5-20t, span is 14-35m, and working temperature is -20~ +40 degrees.
This gantry crane with electric hoist is a regular crane widely used at open ground and warehouses to load or grab materials. There are two kinds of operation: ground or air operation. The crane power supply can be through cable car and cable drum reel, and customers can choose one of them.
.jpg)
.jpg)
|
Lifting capacity |
T |
3 |
5 |
10 |
16 |
20 |
|||
|
Operation type |
|
Handle/remote control/cab |
|||||||
|
Speed |
Hoist lifting |
m/min |
8 ,8/0.8 |
8,8/0.8 |
7,7/0.7 |
3.5 |
3.5 |
||
|
Hoist travelling |
m/min |
20 |
20 |
20 |
20 |
20 |
|||
|
Crane travelling |
Handle /remote control |
20 |
20 |
20 |
20 |
20 |
|||
|
cab |
30,40 |
30,40 |
30,40 |
30,40 |
30,40 |
||||
|
Motor |
Hoist lifting |
Type /kw |
ZD41-4/4.5 |
ZD141-4/7.5 ZDS10.8/4.5 |
ZD151-4/13 ZDS11.5/4.5 |
ZD151-4/13 |
ZD152-4/18 |
||
|
Hoist travelling |
ZDY12-4/0.4 |
ZDY121-4/0.8 |
ZDY21-4/0.8×2 |
ZDY121-4/0.8×2 |
YZD-4/0.8×4 |
||||
|
trolley travelling |
Handle /remote control |
ZDY21-4/0.8×2 |
YZR132M1-6/2.2×2 |
YZR160M1-6/6.3×2 |
YZR160M1-6/6.3×2 |
YZR160M1-6/6.3×2 |
|||
|
ZDY21-4/1.5×2 |
YZR132M2-6/3.7×2 |
YZR160M2-6/8.5×2 |
YZR160M2-6/8.5×2 |
||||||
|
Handle /remote control |
ZDR22-4/1.5×2 |
YZR132M2-6/3.7×2 |
YZR160M1-6/6.3×2 |
YZR160M2-6/8.5×2 |
YZR160M2-6/8.5×2 |
||||
|
ZDR24-4/2.2×2 |
YZR160M1-6/5.5×2 |
YZR160L2-6/11×2 |
YZR160L2-6/11×2 |
||||||
|
Electric hoist |
Type |
CD1/MD1 |
CD1/MD1 |
CD1/MD1 |
CD1 |
HC |
|||
|
Lifting height |
m |
6,9 |
|||||||
|
Work classifications |
|
A5 |
|||||||
|
Power |
|
380V 50HZ 3phase AC |
|||||||
|
Span |
m |
12,16,20,24,30 |
|||||||
